Hadoop高可用集群部署

作者：事業二部 2023-11-07 07:30:18

大數據 Hadoop

在master節點中使用yarn rmadmin -getAllServiceState命令查看各個節點ResourceManager狀態，接下來停止active狀態節點的ResourceManage進程，ResourceManage active自動跳轉到其他節點，集群仍可用，隨后再啟動該節點ResourceManager進程，最后再次查看狀態，F(xiàn)ailed狀態恢復為standby。

背景

生產中Hadoop分布式集群中可能存在著單點故障問題，如果Namenode宕機或是軟硬件升級，集群將無法使用，所以進行搭建高可用的來消除單點故障。

Hadoop介紹

Hadoop集群一般為一個NameNode和ResourceManager，但在實際生產環境中，若恰好具有NameNode和ResourceManager的節點出現故障，那么整個Hadoop集群將會崩潰，這是因為在HDFS中NameNode是系統的核心節點，ResourceManager負責整個系統的資源管理和分配。

為了解決單點故障問題，在Hadoop2后中引入了高可用機制，支持NameNode和ResourceManager一個主節點和一個備用節點，而在Hadoop3中繼續對其進行了優化和提升，它支持一個主節點和多個備用節點。所謂高可用（High Availability, HA）就是7*24 小時不中斷服務，消除單點故障。

Hadoop HA嚴格來說應該分成各個組件的HA機制：HDFS的HA和YARN的HA，可以通過配置多個NameNode和ResourceManager(Active/Standby)實現在集群中的熱備來解決上述問題。

環境準備：

圖片

節點相關進程如下：

圖片

操作系統：centos8
內存：4G
Java 版本：jdk8

HDFS和YARN HA集群搭建

3.1 下載hadoop安裝包

官網https://hadoop.apache.org/下載hadoop 3.3.0安裝包解壓至/usr/local下3臺機器需修改的配置文件目錄為/usr/local/hadoop/etc/hadoop下。

3.2 hadoop.env

export JAVA_HOME=/usr/local/jdk #配置jdk路徑
#添加兩行
export HDFS_JOURNALNODE_USER=root
export HDFS_ZKFC_USER=root

3.3 core-site.xml

<?xml versinotallow="1.0" encoding="UTF-8"?>
<?xml-stylesheet type="text/xsl" href="configuration.xsl"?>
<!-- Put site-specific property overrides in this file. -->
<configuration>
<!-- hdfs分布式文件系統名字/地址 -->
<property>
<name>fs.defaultFS</name>
<value>hdfs://ns</value>
</property>
<!--存放namenode、datanode數據的根路徑 -->
<property>
<name>hadoop.tmp.dir</name>
<value>/usr/local/hadoop/tmp</value>
</property>
<!-- 存放journalnode數據的地址 -->
<property>
<name>dfs.journalnode.edits.dir</name>
<value>/usr/local/hadoop/tmp/jn</value>
</property>
<!-- 列出運行 ZooKeeper 服務的主機端口對 -->
<property>
<name>ha.zookeeper.quorum</name>
<value>hadoop:2181,k8s-2:2181,k8s-3:2181</value>
</property>
</configuration>

3.4 hdfs-site.xml

<?xml versinotallow="1.0" encoding="UTF-8"?>
<?xml-stylesheet type="text/xsl" href="configuration.xsl"?>
<!--
  Licensed under the Apache License, Version 2.0 (the "License");
  you may not use this file except in compliance with the License.
  You may obtain a copy of the License at
    http://www.apache.org/licenses/LICENSE-2.0
  Unless required by applicable law or agreed to in writing, software
  distributed under the License is distributed on an "AS IS" BASIS,
  WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
  See the License for the specific language governing permissions and
  limitations under the License. See accompanying LICENSE file.
-->
<configuration>
    <property>
        <name>dfs.replication</name>
        <value>3</value>
    </property>
    <property>
        <name>dfs.namenode.name.dir</name>
        <value>/usr/local/hadoop/dfs/name</value>
    </property>
    <property>
        <name>dfs.datanode.data.dir</name>
        <value>/usr/local/hadoop/dfs/data</value>
    </property>
    <property>
        <name>dfs.journalnode.edits.dir</name>
        <value>/usr/local/hadoop/dfs/journalnode</value>
        <description>The path where the JournalNode daemon will store its local state.</description>
    </property>
    <property>
        <name>dfs.nameservices</name>
        <value>ns</value>
        <description>The logical name for this new nameservice.</description>
    </property>
    <property>
        <name>dfs.ha.namenodes.ns</name>
        <value>nn1,nn2,nn3</value>
        <description>Unique identifiers for each NameNode in the nameservice.</description>
    </property>
    <property>
        <name>dfs.namenode.rpc-address.ns.nn1</name>
        <value>hadoop:8020</value>
        <description>The fully-qualified RPC address for nn1 to listen on.</description>
    </property>
    <property>
        <name>dfs.namenode.rpc-address.ns.nn2</name>
        <value>k8s-2:8020</value>
        <description>The fully-qualified RPC address for nn2 to listen on.</description>
    </property>
    <property>
        <name>dfs.namenode.rpc-address.ns.nn3</name>
        <value>k8s-3:8020</value>
        <description>The fully-qualified RPC address for nn3 to listen on.</description>
    </property>
    <property>
        <name>dfs.namenode.http-address.ns.nn1</name>
        <value>hadoop:9870</value>
        <description>The fully-qualified HTTP address for nn1 to listen on.</description>
    </property>
    <property>
        <name>dfs.namenode.http-address.ns.nn2</name>
        <value>k8s-2:9870</value>
        <description>The fully-qualified HTTP address for nn2 to listen on.</description>
    </property>
    <property>
        <name>dfs.namenode.http-address.ns.nn3</name>
        <value>k8s-3:9870</value>
        <description>The fully-qualified HTTP address for nn3 to listen on.</description>
    </property>
    <property>
        <name>dfs.namenode.shared.edits.dir</name>
        <value>qjournal://hadoop:8485;k8s-3:8485;k8s-2:8485/ns</value>
        <description>The URI which identifies the group of JNs where the NameNodes will write/read edits.</description>
    </property>
    <property>
        <name>dfs.client.failover.proxy.provider.ns</name>
<value>org.apache.hadoop.hdfs.server.namenode.ha.ConfiguredFailoverProxyProvider</value>
        <description>The Java class that HDFS clients use to contact the Active NameNode.</description>
    </property>
    <property>
        <name>dfs.ha.fencing.methods</name>
        <value>
            sshfence
            shell(/bin/true)
        </value>
        <description>
            A list of scripts or Java classes which will be used to fence the Active NameNode during a failover.
            sshfence - SSH to the Active NameNode and kill the process
            shell - run an arbitrary shell command to fence the Active NameNode
        </description>
    </property>
    <property>
        <name>dfs.ha.fencing.ssh.private-key-files</name>
        <value>/root/.ssh/id_rsa</value>
        <description>Set SSH private key file.</description>
    </property>
    <property>
        <name>dfs.ha.automatic-failover.enabled</name>
        <value>true</value>
        <description>Automatic failover.</description>
    </property>
</configuration>

3.5 mapred-site.xml

<?xml versinotallow="1.0"?>
<?xml-stylesheet type="text/xsl" href="configuration.xsl"?>
<!--
Licensed under the Apache License, Version 2.0 (the "License");
you may not use this file except in compliance with the License.
You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License. See accompanying LICENSE file.
-->
<!-- Put site-specific property overrides in this file. -->
<configuration>
<property>
<name>mapreduce.framework.name</name>
<value>yarn</value>
</property>
<property>
<name>yarn.app.mapreduce.am.env</name>
<value>HADOOP_MAPRED_HOME=/usr/local/hadoop</value>
</property>
<property>
<name>mapreduce.map.env</name>
<value>HADOOP_MAPRED_HOME=/usr/local/hadoop</value>
</property>
<property>
<name>mapreduce.reduce.env</name>
<value>HADOOP_MAPRED_HOME=/usr/local/hadoop</value>
</property>
</configuration>

3.6 yarn-site.xml

<?xml versinotallow="1.0"?>
<!--
  Licensed under the Apache License, Version 2.0 (the "License");
  you may not use this file except in compliance with the License.
  You may obtain a copy of the License at
    http://www.apache.org/licenses/LICENSE-2.0
  Unless required by applicable law or agreed to in writing, software
  distributed under the License is distributed on an "AS IS" BASIS,
  WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
  See the License for the specific language governing permissions and
  limitations under the License. See accompanying LICENSE file.
-->
<configuration>
<property>
    <name>yarn.resourcemanager.ha.enabled</name>
    <value>true</value>
    <description>Enable RM HA.</description>
</property>
<property>
    <name>yarn.resourcemanager.cluster-id</name>
    <value>yrc</value>
    <description>Identifies the cluster.</description>
</property>
<property>
    <name>yarn.resourcemanager.ha.rm-ids</name>
    <value>rm1,rm2,rm3</value>
    <description>List of logical IDs for the RMs. e.g., "rm1,rm2".</description>
</property>
<property>
    <name>yarn.resourcemanager.hostname.rm1</name>
    <value>hadoop</value>
    <description>Set rm1 service addresses.</description>
</property>
<property>
    <name>yarn.resourcemanager.hostname.rm2</name>
    <value>k8s-2</value>
    <description>Set rm2 service addresses.</description>
</property>
<property>
    <name>yarn.resourcemanager.hostname.rm3</name>
    <value>k8s-3</value>
    <description>Set rm3 service addresses.</description>
</property>
<property>
    <name>yarn.resourcemanager.webapp.address.rm1</name>
    <value>hadoop:8088</value>
    <description>Set rm1 web application addresses.</description>
</property>
<property>
    <name>yarn.resourcemanager.webapp.address.rm2</name>
    <value>k8s-2:8088</value>
    <description>Set rm2 web application addresses.</description>
</property>
<property>
    <name>yarn.resourcemanager.webapp.address.rm3</name>
    <value>k8s-3:8088</value>
    <description>Set rm3 web application addresses.</description>
</property>
<property>
    <name>hadoop.zk.address</name>
    <value>hadoop:2181,k8s-2:2181,k8s-3:2181</value>
    <description>Address of the ZK-quorum.</description>
</property>
</configuration>

3.7 workers

hadoop
k8s-2
k8s-3

安裝zookeeper

版本：zookeeper-3.6.4

通過https://www.apache.org/dyn/closer.lua/zookeeper/zookeeper-3.6.4/apache-zookeeper-3.6.4-bin.tar.gz 下載安裝包，3臺機器進行解壓配置安裝。

echo "1" > /data/zookeeperdata/myid #不同機器id不同

zoo.cfg配置如下：

tickTime=2000
initLimit=10
syncLimit=5
dataDir=/data/zookeeperdata #數據目錄
dataLogDir=/data/zookeeperdata/logs #日志目錄
clientPort=2181 #端口
server.1=192.xxx.xxx.128:2888:3888
server.2=192.xxx.xxx.132:2888:3888
server.3=192.xxx.xxx.131:2888:3888

環境變量配置

vi /etc/profile

export JAVA_HOME=/usr/local/jdk
export HAD00P_HOME=/usr/local/hadoop
export PATH=$PATH:$HADOOP_HOME/bin
export HADOOP_CLASSPATH=`hadoop classpath`

source /etc/profile

啟動集群

在所有節點上使用rm -rf /usr/local/hadoop/dfs命令，刪除之前創建的存儲路徑，同時在master節點上執行mkdir -p /usr/local/hadoop/dfs/name /usr/local/hadoop/dfs/data /usr/local/hadoop/dfs/journalnode，再次創建存儲路徑。

在所有節點上使用rm -rf /usr/local/hadoop/tmp /usr/local/hadoop/logs && mkdir -p /usr/local/hadoop/tmp /usr/local/hadoop/logs命令，重置臨時路徑和日志信息。

通過以上步驟，Hadoop HA集群就配置完成了，當?shù)谝淮螁親A集群時需要依次執行以下命令：

$ZOOKEEPER_HOME/bin/zkServer.sh start # 開啟Zookeeper進程(所有節點上執行)
$HADOOP_HOME/bin/hdfs --daemon start journalnode # 開啟監控NameNode的管理日志的JournalNode進程(所有節點上執行)
$HADOOP_HOME/bin/hdfs namenode -format # 命令格式化NameNode(在master節點上執行)
scp -r /usr/local/hadoop/dfs k8s-2:/usr/local/hadoop  # 將格式化后的目錄復制到slave1中(在master節點上執行)
scp -r /usr/local/hadoop/dfs k8s-3:/usr/local/hadoop   # 將格式化后的目錄復制到slave2中(在master節點上執行)
$HADOOP_HOME/bin/hdfs zkfc -formatZK # 格式化Zookeeper Failover Controllers(在master節點上執行)
start-dfs.sh&&start-yarn.sh # 啟動HDFS和Yarn集群(在master節點上執行)

若不是第一次啟動HA集群（常規啟動HA集群），則只需要依次執行以下命令：

$ZOOKEEPER_HOME/bin/zkServer.sh start    # 開啟Zookeeper進程(所有節點上執行)
start-all.sh或者$HADOOP_HOME/sbin/start-dfs.sh && $HADOOP_HOME/sbin/start-yarn.sh # 啟動HDFS和Yarn集群(在master節點上執行)

啟動完成后每個節點使用jps命令會出現NameNode、DataNode、ResourceManager、NodeManager、JournalNode、DFSZKFailoverController、QuorumPeerMain和Jps 8個進程。

圖片

圖片

通過頁面訪問查看：

http://192.xxx.xxx.128:9870/

圖片

http://192.xxx.xxx.128:8088/cluster/nodes

圖片

hdfs HA驗證

6.1 查看各個節點NameNode狀態

圖片

6.2 驗證hdfs的高可用

在開啟HA集群并成功啟動的情況下，在master節點中使用hdfs haadmin -getAllServiceState命令查看各個節點NameNode狀態，接下來停止active狀態節點的NameNode進程。

圖片

Namenode active自動跳轉其他節點，集群仍可用。

圖片

圖片

隨后再啟動該節點NameNode進程，最后再次查看狀態，可以發現HDFS HA是正常的，并且沒有發生搶占。

圖片

驗證yarn 高可用

在master節點中使用yarn rmadmin -getAllServiceState命令查看各個節點ResourceManager狀態，接下來停止active狀態節點的ResourceManage進程，ResourceManage active自動跳轉到其他節點，集群仍可用，隨后再啟動該節點ResourceManager進程，最后再次查看狀態，F(xiàn)ailed狀態恢復為standby。

圖片

若要關閉集群可以master使用$HADOOP_HOME/sbin/stop-yarn.sh && $HADOOP_HOME/sbin/stop-dfs.sh命令或者stop-all.sh 即可關閉hadoop集群，然后關閉zookeeper,三臺機器分別執行/data/apache-zookeeper-3.6.4-bin/bin/zkServer.sh stop。

責任編輯：武曉燕來源： IT那活兒

Hadoop 高可用

點贊

51CTO技術棧公眾號

業務
速覽

媒體

51CTO CIOAge HC3i

社區

51CTO博客鴻蒙開發者社區 AI.x社區

教育

51CTO學堂精培企業培訓 CTO訓練營
